MIL-STD-1553 serial bus trigger settings panel
NOTE. Requires option SRAERO.
Field or control Description
Source Select the MIL-STD-1553 bus on which you want to trigger.
Trigger On Select the type of information on which to trigger.
Sync Sets to trigger on a Sync condition.
Available when Trigger On = Sync.
Transmit/Receive Bit Sets the transmit or receive bit on which to trigger.
Available when Trigger On = Command.
Trigger When RT Address Sets to trigger when the specified RT address condition occurs.
Available when Trigger On = Command or Status.
Parity Sets to trigger on the selected parity bit logic state.
Available when Trigger On = Command, Status, or Data.
Address Sets the address pattern on which to trigger.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Command or Status.
Low Address Sets the low value of the address pattern range on which to trigger.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Available when Trigger When RT Address = Inside Range or Outside Range.
High Address Sets the high address of the address pattern range on which to trigger.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Available when Trigger When RT Address = Inside Range or Outside Range.
Subaddress/Mode Sets the subaddress or mode pattern on which to trigger.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Command.
Menus and dialog boxes
360 MSO54, MSO56, MSO58, MSO58LP, MSO64 Help
