SENT serial bus trigger settings panel
NOTE. Requires option SRAUTOSEN.
Field or control Description
Source Select the SENT bus on which to trigger.
Trigger On Select the type of information on which to trigger.
Channel Sets the SENT channel type on which to trigger.
Available when Trigger On = Start of Packet.
Status / Communications Sets the value of the status/communications nibble on which to trigger.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Fast Channel.
Fast Channel 1 Sets the condition and value of the fast channel 1 data on which to trigger.
Tap the down arrow and select the condition on which to trigger (=, ≠, >, <, ≥, ≤). The default is
=.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Fast Channel.
Fast Channel 2 Sets the condition and value of the fast channel 2 data on which to trigger.
Tap the down arrow and select the condition on which to trigger (=, ≠, >, <, ≥, ≤). The default is
=.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Fast Channel.
Counter Sets the condition and value of the counter data on which to trigger.
Tap the down arrow and select the condition on which to trigger (=, ≠, >, <, ≥, ≤). The default is
=.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Fast Channel.
Inverted Nibble Sets the value of the inverted nibble data on which to trigger.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Fast Channel and the bus is set up for 1 fast data channel and
Data Nibbles is set to 6 Secure.
Message ID Sets the value of the message ID data on which to trigger.
Available when Trigger On = Slow Channel.
Menus and dialog boxes
MSO54, MSO56, MSO58, MSO58LP, MSO64 Help 367
