Field or control Description
Copy Trigger Settings to
Search
Sets the search criteria to match the current oscilloscope trigger settings.
Copy Search Settings to
Trigger
Sets the current oscilloscope trigger settings to match the search criteria.
MIL-STD-1553 serial bus search configuration menu
Use the MIL-STD-1553 Search configuration menu to define conditions to search for and mark on an XxMIL-STD-1553X bus
waveform. You can have multiple searches on the same bus.
NOTE. Requires option SRAERO.
Field or control Description
Display Enables or disables displaying search marks on this search.
Stop Acquisition if Event
Found
Stops input acquisition when the search event occurs. Default is not enabled.
Source Select the MIL-STD-1553 bus that you want to search.
Mark On Select the type of information for which to search.
Transmit/Receive Bit Sets the transmit or receive bit state for which to search.
Only available when Mark On = Command.
Mark when RT Address Sets the RT address condition for which to search.
When set to Inside Range or Outside Range, fields are displayed to set a low and high
address for the specified search range.
Only available when Mark On = Command.
Parity Sets the parity state for which to search.
Only available when Mark On = Command.
Address Sets the address value for which to search.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Command.
Low Address Sets the low address value for which to search.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Command and Mark When RT Address = Inside Range or
Outside Range
