ARINC 429 serial bus trigger settings panel
NOTE. Requires option SRAERO.
Field or control Description
Source Select the ARINC429 bus on which you want to trigger.
Trigger On Select the type of information on which to trigger.
Trigger When Label Trigger when the label data meets the specified condition
Available when Trigger On = Label.
Label Sets the label pattern on which to trigger.
Tap the Binary, Hex, or Octal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Label or Label & Data.
Label Low Sets the low value of the label pattern range on which to trigger.
Tap the Binary, Hex, or Octal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Label and Trigger When Label = Inside Range or Outside
Range.
Label High Sets the high value of the label pattern range on which to trigger.
Tap the Binary, Hex, or Octal field and use the A and B knobs to select and change the values.
Or double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Label and Trigger When Label = Inside Range or Outside
Range.
Data Sets to trigger when the specified data bits condition occurs.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Data or Label & Data.
Data Low Sets the low value of the data pattern range on which to trigger.
Tap the Binary, Hex, or Octal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Data and Trigger When Data = Inside Range or Outside
Range.
Data High Sets the high value of the data pattern range on which to trigger.
Tap the Binary, Hex, or Octal field and use the A and B knobs to select and change the values.
Or double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Data and Trigger When Data = Inside Range or Outside
Range.
Menus and dialog boxes
MSO54, MSO56, MSO58, MSO58LP, MSO64 Help 343
