Audio serial bus search configuration menu
Use the Audio Search configuration menu to define conditions to search for and mark on an Audio bus waveform. You can have
multiple searches on the same bus.
NOTE. Requires option SRAUDIO.
Field or control Description
Display Enables or disables displaying search marks on this search.
Stop Acquisition if Event
Found
Stops input acquisition when the search event occurs. Default is not enabled.
Source Select the Audio bus to search.
Mark On Select the type of information for which to search.
Data Sets the data pattern for which to search. Use in conjunction with the Mark When field to specify
the exact search condition.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Data.
Word Sets the audio word channel for which to search.
Only available when Mark On = Data.
Mark When Sets the mark when condition for the specified data pattern.
When set to Inside Range or Outside Range, fields are displayed to set a high and low
boundary pattern for the specified search range.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Data.
A, B knob controls Use the A knob to select (highlight) the digit(s) to change.
Use the B knob to change the value of the digit(s).
Copy Trigger Settings to
Search
Sets the search criteria to match the current oscilloscope trigger settings.
Copy Search Settings to
Trigger
Sets the current oscilloscope trigger settings to match the search criteria.
Menus and dialog boxes
MSO54, MSO56, MSO58, MSO58LP, MSO64 Help 233
