SPMI serial bus search configuration menu
Use the SPMI Search configuration menu to define conditions for which you want to search and mark on an SPMI bus signal.
You can have multiple searches on the same bus.
NOTE. Requires option SRPM.
Field or control Description
Display Enables or disables displaying marks from this search on the bus waveform.
Stop Acquisition if Event
Found
Stops input acquisition when the search event occurs. Default is not enabled.
Source Select the SPMI bus for which to search.
Mark On Select the type of information for which to search.
Slave Address Sets the slave address value for which to search.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Mark On = Reset, Authenticate, Register Read, Register Write, Extended
Register Read, Extended Register Write, Ext. Register Read Long, Ext. Register Write
Long, DD Block Slave Read, or Register 0 Write.
Master Address Sets the master address value for which to search.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Mark On = Master Read, Master Write, or DD Block Master Read.
Register Address Sets the register address value for which to search.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Mark On = Master Read, Master Write, Register Read, Register Write,
Extended Register Read, Extended Register Write, Ext. Register Read Long, or Ext.
Register Write Long.
Data Sets the data value for which to search.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Mark On = Master Read, Master Write, Register Read, Register Write,
Extended Register Read, Extended Register Write, Ext. Register Read Long, Ext. Register
Write Long, DD Block Master Read, DD Block Slave Read, or Register 0 Write.
Data Bytes Sets the number of data bytes for which to search. Tap the field and use the A knob to change
the value. Or double-tap on the field and use the virtual keypad to enter a value.
Available when Mark On = Extended Register Read, Extended Register Write, Ext. Register
Read Long, or Ext. Register Write Long.
Menus and dialog boxes
MSO54, MSO56, MSO58, MSO58LP, MSO64 Help 247
