FlexRay serial bus menu fields and controls.
Field or control Description
Display Turns on or off displaying the bus on the Waveform view.
Label Enter a label for the bus. The default label is the selected bus type.
To enter label text, double-tap the field and enter label using the virtual keyboard, or tap the
field and enter text using an attached keyboard.
Position Sets the vertical position of the bus waveform. The default position is vertically centered in a
slice (in Stacked mode), or center screen in Overlay mode. The unit of position is screen
divisions.
Set to 0 Sets the vertical position to 0 divisions (centered vertically in a slice or on the screen.
Bus Type Set to FlexRay.
Signal Type Select the FlexRay signal type being measured.
Channel Type Set to A or B channel.
Source Select the FlexRay signal source.
Threshold Sets the threshold value for the TX or RX signal type.
High Threshold, Low
Threshold
Sets the high and low threshold values for the BM Inverted and Bdiff/BP signal types.
Bit Rate Select a bit rate. To set a custom bit rate, select Custom and enter a value in the Custom Rate
field.
Display Format Sets the waveform view to show just the decoded bus information, or the decoded bus plus the
source signal waveforms.
Decode Format Sets the decode format used to display the bus information. Formats are Hex and Binary.
Menus and dialog boxes
MSO54, MSO56, MSO58, MSO58LP, MSO64 Help 201
