MIL-STD-1553 serial bus menu fields and controls.
Field or control Description
Display Turns on or off displaying the bus on the Waveform view.
Label Enter a label for the bus. The default label is the selected bus type.
To enter label text, double-tap the field and enter label using the virtual keyboard, or tap the
field and enter text using an attached keyboard.
Position Sets the vertical position of the bus waveform. The default position is vertically centered in a
slice (in Stacked mode), or center screen in Overlay mode. The unit of position is screen
divisions.
Set to 0 Sets the vertical position to 0 divisions (centered vertically in a slice or on the screen.
Bus Type Set to MIL-STD-1553.
Polarity Select the polarity to match the MIL-STD-1553 bus being acquired.
Source Select the MIL-STD-1553 signal source.
High Threshold, Low
Threshold
Sets the valid high and low threshold values for the signal source.
RT Maximum Sets the maximum valid response time (RT) for a command.
RT Minimum Sets the minimum valid response time (RT) for a command.
Display Format Sets the waveform view to show just the decoded bus information, or the decoded bus plus the
source signal waveforms.
Decode Format Sets the decode format used to display the bus information. Formats are Hex, Binary, Mixed
ASCII, and Mixed Hex.
Other bus types. Other serial bus types, such as CAN, LIN, Ethernet, and so on, are available as purchasable options. Once
purchased and installed, the new bus types are shown in the Bus Type menu. The serial bus options also add corresponding bus
trigger capabilities to the Trigger menu.
ARINC 429 serial bus menu on page 192
Audio serial bus configuration menu on page 194
CAN serial bus configuration menu on page 196
Ethernet serial bus menu on page 198
I2C serial bus configuration menu on page 202
LIN serial bus configuration menu on page 204
Parallel Bus configuration menu on page 207
RS232 serial bus menu on page 209
SENT serial bus configuration menu on page 211
SPI serial bus configuration menu on page 213
SPMI serial bus configuration menu on page 215
USB serial bus configuration menu on page 217
Menus and dialog boxes
206 MSO54, MSO56, MSO58, MSO58LP, MSO64 Help
