Field or control Description
Cycle Count Enter the cycle count pattern for which to search. Use in conjunction with the Mark When field
to specify the exact search condition.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Cycle Count or Header Fields.
Payload Length Enter the payload length pattern for which to search. Use in conjunction with the Mark When
field to specify the exact search condition.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Header Fields.
Header CRC Enter the header CRC pattern for which to search. Use in conjunction with the Mark When field
to specify the exact search condition.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Header Fields.
Data Bytes Enter the number of data bytes for which to search (one to sixteen bytes). Use the A knob to
change the value.
Only available when Mark On = Data or Identifier & Data.
Data Enter the data pattern for which to search. The number of bits shown depends on the Data
Bytes setting. Use in conjunction with the Mark When field to specify the exact search
condition.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Data or Identifier & Data.
Byte Offset Sets the byte offset (Don't Care or the number of bytes). Tap the field and use the A knob to
change the value.
Only available when Mark On = Data or Identifier & Data.
Mark When Sets the mark when condition.
When set to Inside Range or Outside Range, fields are displayed to set a high and low
boundary pattern for the specified search range.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Frame ID, Cycle Count, Data, or Identifier & Data.
Frame Type Sets the end of frame type for which to search.
Only available when Mark On = End of Frame.
