Setup & Hold Search configuration menu fields and controls.
Field or control Description
Display Sets the display of the mark icons on or off. If you have multiple searches defined, the control
turns off just the marks for the selected search.
Stop Acquisition if Event
Found
Stops input acquisition when the search event occurs. Default is not enabled.
Search Type Set to Setup & Hold.
Clock Source Sets the signal to use as the clock. The clock source can be an analog, digital, math, or
reference waveform.
Clock Level Sets the threshold level that the clock signal must pass through to be considered a valid
transition. The clock threshold value is independent of the input signal threshold(s).
Clock Edge Sets the polarity of the clock edge (rising or falling) for evaluating the other menu conditions.
The Logic menu also lets you set the clock edge to either edge.
Data Sources Sets the data signal source(s). All selected sources must meet the specified setup and hold
times. See Setup and Hold Search - Define Inputs configuration menu on page 260.
Setup Time Sets the length of time that data signal should be stable and not change before a clock edge
occurs.
Hold Time Sets the length of time that data signal should be stable and not change after a clock edge
occurs.
Copy Trigger Settings to
Search
Sets the search criteria to match the current oscilloscope trigger settings.
Copy Search Settings to
Trigger
Sets the current oscilloscope trigger settings to match the search criteria.
Other search types.
Bus Search configuration menus on page 230
Edge Search configuration menu on page 250
Logic search configuration menu on page 251
Pulse Width Search configuration menu on page 253
Rise/Fall Time Search configuration menu on page 255
Runt Search configuration menu on page 257
Timeout Search configuration menu on page 260
Window Search configuration menu on page 262
Menus and dialog boxes
MSO54, MSO56, MSO58, MSO58LP, MSO64 Help 259
