Analyzing waveforms Set up a visual search

6. Only the active visual search area is displayed. Press the Mark Next and the Mark Prev buttons to

move the a

ctive area to other visual search areas. Active search areas only appear in the zoom window.

Use the other Analyze Search control windows to control or view the results of the Visual Search.

What

do you want to do next?

Learn about bus setups (see page 95).

Learn about trigger setups (see page 385).

Learn about setting up a Visual Trigger (see page 459).

Learn about setting up a search (see page 300).
