Trigger setups Set up a Glitch trigger

The trigger can also be qualiﬁed by the logical state of other channels or by a bus pattern (MSO70000C

Series only). When you click on the trigger window controls, the trigger graphic

(see page 386) shows the

trigger seque

nce.

What do you want to do next?

Learn m ore about other trigger types. (see page 386)

Return to the Trigger Setup control window. (see page 385)

DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 425
