SDI7 Dual Channel SD/HD/3G SDI Video Generator module
LOGO. Select th
is menu item, and then press the ENTER button to acce ss the
LOGO submenu where you can select a logo to overlay the output signal in a
specified position. (See page 3-295.)
ID TEXT. Select this menu item, and then press the ENTER button to access the
ID TEXT submenu where y ou can edit the text to overlay the output signal in a
specified po
sition. (See page 3-297.)
CIRCLE. Select this menu item, and then press the ENTER button to access the
CIRCLE submenu where you can specify a circle size and position to overlay
the output signal. (See page 3-301.)
BURNT-IN
TIMECODE. Select this menu item, and then press the ENTER button
to access the BURNT-IN TIMECODE submenu where you can enable or disable
the burnt-in timecode, and set the size and position of the timecode overlay on
the output signal. (See page 3-301.)
BLINK. Sets the blinking mode for the enabled overlay. Use the left (◄)or
right
(►) arrow button to select one of the following blink modes, and then press
the ENTER buttontoconfirm the selection.
Disab
le: Disables the blinking function of the overlay.
Fast: Sets the overlay to blink at approximately 0.5 second intervals.
Slow: Sets the overlay to blink at approximately 1.0 second intervals.
BOR
DER. Displays a b lack border around the text and circle overlays when
enabled. Select this menu item, and then use the left (◄)orright(►) arrow button
to select Enable or Disable.PresstheENTER buttontoconfirm the selection.
NOTE. Turn on the border to provide cleaner transitions between the overlay and
the test signal. This is especially useful for 4:2:2 format signals, which may have
some ringing when the border is turned off.
3–294 TG8000 Multiformat Test Signal Generator User Manual
