18. Press the left (
◄)orright(►)arrowbuttontoselectBlack Burst,thenpress
the ENTER button.
19. Connect the BLACK 1 connector to the NTSC/PAL waveform monitor using
the 75 Ω BNC cable.
20. Set the waveform monitor to view the black burst signal.
21. Check that the appropriate black burst signal is displayed.
22. Press the BACK button twice to display the SELECT OUTPUT menu.
23. Press the left (◄)orright(►) arrow button to select BLACK 2, then press
the E
NTER button.
24. Repeat steps 17 and 18.
25. Connect the BLACK 2 connector to the NTSC/PAL waveform monitor using
the 75 Ω BNC cable.
26. Set the waveform monitor to view the black burst signal.
27. Check that the appropriate black burst signal is displayed.
28. Press the BACK button twice to display the SELECT OUTPUT menu.
29. Press the left (◄)orright(►) arrow button to select BLA
CK 3 and then
press the ENTER button. This displays the SELECT FORMAT submenu.
30. Press the left (◄)orright(►) arrow button to select 1080 60i andthenpress
the ENTER button.
31. Connect the BLACK 3 connector to the HDTV wave form monitor using
the 75 Ω BNC cable.
32. Check that the appropriate HDTV trilevel sync signal is displayed.
ATG7 module functional
check
Use the following procedure to check that the ATG7 Analog Test Generator
module is functional:
Required equipment.
NTSC/PAL waveform monitor
75 Ω BNC cable
75 Ω terminator
Procedure.
1. Install the module into the TG8000 mainframe. (See page 1-11, Module
installation and removal.)
2. Power on the TG8000 mainframe by connecting it to the power source. The
initialization process for all installed modules is executed.
TG8000 Multiformat Test Signal Generator User Manual 1–19
