Appendix A: Specifications
Recorder Spec
ifications
Table 8: Recorder
Characteris
tic
Description
TrendPlot (C
hannel 1, 2, 3, 4)
Chart recor
der mode that plots a graph of min and max values of oscilloscope measurements (four max) over time.
Measurement speed
>5 measure
ments/s
Time/div 5 s/div to 3
0 min/div
Record si
ze (min, max, average)
≥18000 points
Recorded time span 60 min to 22 days
Time reference time from start, time of day
Scope Roll Mode
Records oscilloscope waveforms in deep memory while displaying the waveform in Roll mode.
Source Input Ch1, Ch2, Ch3, Ch4
Maximum sample speed (5 ms/div to 1 min/div) 4 × 125 MS/s
Glitch capture (5 ms/div to 1 min/div)
8ns
Glitch capture (2 min/div)
8ns
Time/div in normal mode 5 ms/div to 2 min/div
Record size 30 k to 37.5 k points per trace
Re
corded time span
6s
to 48 hours
Acquisition modes
Si
ngle Sweep, Continuous Roll, Start/Stop on Trigger
T
ime reference
t
ime from start, time of day
Zoom, Data Log, and Cursors Specifications
Ta ble 9: Zoom, Data Log, and Cursors
Characteristic Description
Zoom
Zoom ranges from full record overview to detailed v iew of
individual samples
Data Log
Displays a maximum of 100 captured quad input Scope screens
Data Log modes
Step by Step, Replay as Animation
Cursor measurements
Cursor modes
single vertical c ursor, dual vertical cursors, dual horizontal
cursors
THS3000 Series Oscilloscopes User Manual 89
