Operating Basics
Connections wi
th a ground lead. The voltage applied to the reference lead is also
present on the ground ring near the probe tip. The ground ring is shown here.
WARNING. To avoid electrical shock, always use the insulation sleeve or the
probe tip when using the probe reference (ground) lead. The voltage applied to
the reference lead is also present on the ground ring near the probe tip. (See
Figure 16.)
Figure 1
6: Probe tip ground ring
THS3000 Series Oscilloscopes User Manual 27
