Appendix A: Specifications
Table 14: Inter
face Ports
Port Description
USB-host port
1
Directly conn
ects to external flash memory drive for storage of waveform data, measurement results,
instrument settings and screen copies.
Mini-USB-B port Connects to a PC for screen images, settings, and data transfer using OpenChoice™ software.
Note: Remote control and data transfer via the mini-USB port is not possible when saving or recalling data through the USB-host port.
1
Maximum USB memory
size supported is 2 GB
Table 15: Mechanical
Characteristic Description
Size 265 x 190 x 70 mm (10.5 x 7.5 x 2.8 in)
Weight
2.2 kg (4.8 lbs) including battery
Table 16: Environmental
Characteristic Description
Environmental
MIL-PRF-28800F, Class 2
Temperature
Operating
Battery installed
0to40°C(32to104°F)
No battery installed
0to50°C(32to122°F)
Storage –20 to +60 °C (–4 to +140 °F)
Humidity (maximum relative)
Operating
0to10°C(32to50°F)
noncondensing
10 to 30 °C (50 to 86 °F) 95% (±5%)
30 to 40 °C (86 to 104 °F) 75% (±5%)
40 to 50 °C (104 to 122 °F) 45% (±5%)
Storage
-20to+60°C(-4to+140°F)
noncondensing
Altitude
Operating 3 km (10 000 feet)
Storage 12 km (40 000 feet)
Vibration
Sinusoidal (operating)
maximum 3 g, according to Per MIL-PRF-28800F, class 2
Random (non operating) 0.03 g
2
/Hz, according to Per MIL-PRF-28800F, class 2
Shock (operating)
maximum 30 g, according to Per MIL-PRF-28800F, class 2
92 THS3000 Series Oscilloscopes User Manual
