Appendix A: Specifications
Ta ble 11: Power (cont.)
Characteristic Description
Power adapter 119-7900-xx Line cord options
• Option A0 North American line cord
• Option A1 European line cord
• Option A2 United Kingdom line cord
• Option A3 Australian line cord
• Option A5 Switzerland line cord
• Option A6 Japanese line cord
• Option A10 China line cord
• Option A11 India line cord
• Option E1 U niversal Euro & UK
Line frequency
50 and 60 Hz
Table 12: Probe Calibration Output Signal
Characteristic Description
Vo ltage
1.225 V
p-p
±1.5%
Frequency
500 Hz square wave ±20%
Output impedance 1k Ω
Manual pulse adjustment and automatic DC adjustment with probe check
Table 13: Memory
Characteristic Description
Number of oscilloscope memories
30
Each memory can contain four waveforms plus corresponding setups
Number of recorder memories
10
Each memory can contain:
a quad (4 channel) input TrendPlot
a quad (4 channel) input Scope Record (Roll Mode)
100 quad (4 channel) input Scope screens (Replay)
Number of Screen Images memory
9
Each memory can contain one screen image
THS3000 Series Oscilloscopes User Manual 91
