Appendix A: Specifications
Table 9: Zoom, Data Log, and Cursors (cont.)
Characteristic Description
Markers automatic markers at cross points
Measurements value at cursor 1
value at cursor 2
difference between values at cursor 1 and 2
time between cursors
RMS between cursors
Time of Day (Recorder modes)
Time from Start (Recorder modes)
Rise Time, fall time
A × s (current over time between cursors)
V × s (voltage over time between cursors)
W × s (power over time between cursors using powertrace
Ch1xCh2 or Ch3xCh4)
Miscellaneous Specifications
Table 10: Display
Characteristic Description
View area
126.8 × 88.4 m m (4.99 × 3.48 inches)
Resolution 320 × 240 pixels
Backlight
LED (temperature compensated)
Brightness
Power adapter
200 cd/m
2
Battery power
90 cd/m
2
Display auto-off time (battery saving)
30 seconds, 5 minutes, or disabled
Table 11: Power
Characteristic Description
Rechargeable Li-ion battery (THSBAT)
Operating time up to 7 hours (low intensity)
Charging time
5 hours
Capacity/voltage 52 Wh / 10.8 V
Lifetime (>80 % capacity) 300× charge/discharge
Allowable ambient temperature during charging
0to40°C(32to104°F)
Auto power-down time (battery saving)
5 min, 30 min, or d isabled
90 THS3000 Series Oscilloscopes User Manual
