Introduction
In addition to a product and feature description, this chapter covers the following
topics:
How to perform a quick functional check, install and c ompensate passive
probes, compensate the signal path, and set the time and date
How to use the front panel and menu system
How to identify the instrument controls and connectors
This chapter provides information about instrument setup, menus, and basic
functions. This introduction does not cover all of the capabilities of the instrument
but gives basic examples to show how to use the menus and perform basic
operations.
Product Description
The Tektronix THS3024 and THS3014 Four Channel Handheld Oscilloscopes are
rugged, handheld oscilloscopes ideal for the lab and field.
General Features
Four fully isolated input channels
Volts, Time, Frequency and Watts cursor measurements
Bright, high contrast QVGA color display
7 hour battery operation or external AC/DC adapter power
21 automatic measurements
Comprehensive data logging and analysis capabilities
USB 2.0 device and host support for exchanging images, waveforms, and
settings (maximum supported USB 2 .0 memory size is 2 GB)
Tektronix OpenChoice® Desktop software for capturing screen images,
waveforms, and settings
Key Features
Autoset and Autoranging for quick setup and hands-free operation
200 MHz bandwidth (3024 model)
100 MHz bandwidth (3014 model)
5 GS/s maximum sampling rate (3024 model)
Waveform averaging and enveloping with hardware peak detection
Advanced pulse and video trigger capability
THS3000 Series Oscilloscopes User Manual 1
