Appendix A: Specifications
Introduction
Performance
Characteristics
Tektronix guarantees the properties expressed in numerical values with the stated
tolerance. Specified non-tolerance numerical values indicate those that could be
nominally e
xpected from the mean of a range of identical oscilloscopes.
The oscilloscope meets the specified accuracy 30 minutes and two complete
acquisiti
ons after power on. Specifications are based on a 1-year calibration cycle.
Environmental Data
The environmental data in this manual are based on the results of the verification
procedures.
Safety C
haracteristics
The oscilloscope was designed and tested in accordance with Standards IEC/EN
61010-1:2001 Pollution Degree 2 (According to CE marking), UL 61010-1:2004,
CAN/CSA-C22.2 No. 61010-1-04 (including approval), Safety Requirements for
Electr
ical Equipment for Measurement, Control, and Laboratory Use.
This manual contains information and warnings that must be followed by the
user t
o ensure safe operation and to keep the o scilloscope in a safe condition.
Use of this equipment in a manner not specified may impair protection provided
by the equipment.
General Specifications
Table 5: Record Length (Samples/points per input)
Mode Glitch detect on Glitch detect off Maximum sample rate
Short 300 min/max pairs
3k true samples compressed into 1 screen
(300 samples per screen)
Long
300 min/max pairs
10k true samples compressed into
1 screen (use Zoom and Scroll to see
w
aveform details)
5 G S/s (THS3024 with 1 channel on)
2.
5 GS/s (THS3024 with 1 or 2 channels
on, THS3014 with 2 channels on)
1.25 GS/s (All models and 3 or 4
c
hannels on)
Record Roll 30k to 37.5k samples
4
x 125 MS/s
Trend Plot
>18k min/max/ average values per
measurement
Up to 5 m easurements per second
THS3000 Series Oscilloscopes User Manual 81
