Appendix E
Installation manual to TCS5500 Appendix E ● 109
(S)VGA connector
This connector is used for service applications.
Fig.: (S)VGA connector
Parallel Port connector
This DB-25 connector is used for service applications.
Fig.: DB-25 connector, female
Phoenix contact
A phoenix contact is used to provide the EU5500 and FOC5501
with 48 Volt.
Pin assignment,
Phoenix contact
Pin 1
GND 48V
Pin 2
EARTH
Pin 3
48V
1
2
3
Fig.: Phoenix connector
1
