Telstar LyoQuest - Load Recipe

IM-LYOQUEST-EN-2101 24 / 58
10.2.2.2. LOAD RECIPE
Press th
is button to access the
Lo
ad
R
ecipe
window
:
The recipe to be loaded in the PLC can be selected here. That chosen recipe will be executed
when the automatic mode is on.
Recipe selection button. White if not selected. Green if selected.
Selected recipe confirmation.
Cancel and go to the previous window.
Return to the previous window.
