Tenda O6 User Manual

Web UI Functions
-51-
Ping
Ping is a commonly used diagnosis and troubleshooting command. It can detect whether the device is reachable
to a specified IP address or domain name. If it is reachable, the destination IP address returns response packets.
Parameter description:
Parameter
Description
IP Address
Select an existed IP address in the drowdown list or select Manual to enter an IP address or
domain name.
IP/Domain
Name
When you select Manual, please enter an IP address or domain name to be detected.
Ping Packets
Set up the number of ping packets.
Packet Size
Set up the size of each ping packet.
To check whether an IP or domain name is reachable, do as follows:
1. Log in to the device’s web UI.
2. Go to Advanced > Diagnose.

Tenda O6 Specifications

General

Internal	No
Placement	Wall
Reset button	Yes
Certification	FCC/CE/RoHS
Product color	White
LED indicators	Status
International Protection (IP) code	IP67
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Channel bandwidth	35 MHz
Transmitting power	1 dBmW
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	433 Mbit/s
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Input current	0.5 A
AC input voltage	24 V
Power consumption (max)	9 W
Antenna features	Integrated antenna
Antennas quantity	1
Antenna gain level (max)	16 dBi
USB 2.0 ports quantity	0
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	67.5 mm
Width	94.9 mm
Height	270 mm
