24-Port Managed Gigabit Switch
"xx-xx-xx-xx-xx-xx". A frame that hits this ACE matches this
DMAC value.
VLAN Parameters
VLAN ID Filter
Specify the VLAN ID filter for this ACE.
Any: No VLA
N ID filter is specified. (VLAN ID filter status is
"don't-care".)
Specific: If yo
u want to filter a specific VLAN ID with this ACE,
choose this value. A field for entering a VLAN ID number
appears.
VLAN ID
When "Specific" is selected for the VLAN ID filter, you can enter
a specific VLAN ID number. The allowed range is 1 to 4094. A
frame that hit
s this ACE matches this VLAN ID value.
Tag Priority
Specify the tag priority for this ACE. A frame that hits this ACE
matches this tag priority. The allowed number range is 0 to 7.
T
he value Any means that no tag priority is specified (tag
priority is "don't-care".)
ARP Parameters
The ARP parameters can be configured when Frame Type
"ARP" is selected.
92
