24-Port Managed Gigabit Switch
SMAC Filter
(Only displayed when the frame type is Ethernet Type or
ARP.)
Specify the source MAC filter for this ACE.
Any: No SM
AC filter is specified. (SMAC filter status is
"don't-care".)
Specific: If y
ou want to filter a specific source MAC address
with this ACE, choose this value. A field for entering an SMAC
value appears.
SMAC Value
When "Specific" is selected for the SMAC filter, you can enter a
specific source MAC address. The legal format is
"xx-xx-xx-xx-xx-xx". A frame that hits this ACE matches this
SMAC value.
DMAC Filter
Specify the destination MAC filter for this ACE.
Any: No DM
AC filter is specified. (DMAC filter status is
"don't-care".)
MC: F
rame must be multicast.
BC: Frame must be broadcast.
UC: Frame must be unicast.
Specific: If you
want to filter a specific destination MAC
address with this ACE, choose this value. A field for entering a
DMAC value appears.
DMAC Value
When "Specific" is selected for the DMAC filter, you can enter a
specific destination MAC address. The legal format is
91
