CHASSIS
9C-6
Figure 9C-1. Fuel Tank Removal/Installation
Fuel Tank
Mounting Bolts
Seat Pan
Mounting Bolts
Fuel Hose
Seat Pan
Mounting Bolts
Seat Pan
Seat
Fuel Tank
