HYDRAULICS
8A-1
SECTION 8A. REPAIR, SERVICE TOOLS, AND MATERIALS
MATERIALS REQUIRED
l
Figure 8A-1. Special Bearing Mandrel (Front Traction Motors)
Tools required:
Standard automotive hand tools, including torque
wrench, seal drivers, snap ring pliers, and bearing
driver
Tachometer
Hydra sleuth or in-line tester equipment with load
valve (Figure 8A-1 and Figure 8A-2)
Cleaning materials:
Stoddard solvent or equivalent
Detergent and water
Loctite “Locquic” Primer “T”
Lubricants:
Refer to Section 11
Other service items:
Seal and Repair Kits (available from Jacobsen deal-
ers)
Liquid gasket
Special bearing mandrel
Front Traction Motor Repair JAC 5052
Rear Traction Motor Repair JAC 5053
Blind hole puller (Traction motors)
Hydraulic fitting kit (available from Jacobsen dealers)
Loctite 242 Blue
Flow lock tool JAC 5000
Tool Number
JAC 5052
Tool Number
JAC 5053
Rear Traction Motor
Front Traction Motor
8A
