HYDRAULICS
8A-2
Figure 8A-2. Wheel Restraint
12"
1"
2"
2"
12"
14"
16"
36"
12"
2"
1" Pipe
13-1/2"
Long
1" Pipe Cut to Fit
Between Runners
3/4" NC Ready
Rod 15" Long
2-3/4"
NC Nuts
Two Cargo
Straps
3" Wide
12' Long
