ENGINE
3D-12
Installation
1. Place the radiator in position on the radiator
mount and secure with three bolts on each side.
2. Position the shroud and coolant reservoir on the
radiator. Secure with three bolts on each side.
3. Install the upper and lower radiator hoses. Secure
the hoses with hose clamps.
4. Ensure the drain petcock is closed and fill with a
50/50 mixture of good quality antifreeze and clean
fresh water.
5. Carefully inspect the radiator cap for wear and
damage, replace if necessary. Install the radiator
cap on the radiator.
6. Install the coolant reservoir hose on the radiator
overflow outlet.
7. Install the dust screen over the radiator and
hydraulic oil cooler. Secure the screen with the
knobs.
8. Using the instructions in the Safety and Operation
manual, start the engine and allow the engine to
warm to operating temperature. Fill the coolant
reservoir to the hot level.
EXHAUST SYSTEM
NOTE:
If a change in the color or sound of the exhaust
occurs, stop the engine immediately, identify the
problem and repair as necessary.
NOTE:
Tighten all exhaust manifold hardware evenly.
Inspection
To protect personnel from carbon monoxide poisoning,
inspect the complete exhaust system regularly.
Inspect the exhaust system for cracks, holes, and dis-
tortion (Figure 3D-7). Tighten or replace the exhaust
clamps.
Figure 3D-7. Exhaust System
CAUTION
Do not attempt to service the exhaust system when
the engine is hot. Serious personal injury can occur.
