OPTIONS
13C-18
MICRO HEIGHT ADJUST
ASSEMBLY
The micro height adjust can be disassembled for
repairs as shown in Figure 13C-17.
As the time of assembly make sure the roll pin in the
pin assembly is on the BOTTOM when installing the
pin assembly in the pivot block.
Figure 13C-17. Micro Height Adjustment
LUBRICATION
Use a hand grease gun when lubricating the Turf
Groomer components (Figure 13C-18).
Pump the gun slowly and carefully until a slight amount
of pressure is felt, then stop — DO NOT over grease.
Lubricate the groomer shaft bearings, roller shaft bear-
ings, and clutch monthly.
Lubricate the micro adjusters monthly. Wipe off excess
grease.
Figure 13C-18. Lubrication
