Engine Maintenance
103
1. Elbow—hose fitting (3/8) 26. Lockwasher
2. Kit—sleeve & eyelet (3/8) 27. Flatwasher
3. Nut (3/8) Washer (nylon)
4. Hose (3/8 od x 35 ft lg) 28. Sensor—oil pressure
5. Not Used Nut—sensor
6. Kit—sleeve & eyelet (1/4) Lockwasher
7. Nut (1/4) Flatwasher
8. Elbow 29. Fitting—engine (3.0 in. lg)
9. Hose 30. Pump—fuel (12V)
10. Elbow Pump—fuel (24V)
11. Tee Kit—filter
12. Plug Gasket—fuel pump
13. Filter—fuel 31. Bushing
Filter—fuel (EMI 2000) 32. Fitting—restricted
Adapter—fuel pickup 33. Hose
14. Bracket—fuel filter 34. Clamp—fuel hose
Screw 35. Clip—oil drain hose
Flatwasher 36. Tube—fuel pickup
Nut 37. Bracket—connector
15. Plug—pipe Screw—bracket
16. Plug—pipe Flatwasher
17. Filter—oil bypass Nut
Filter—oil bypass (EMI 2000) 38. Bracket—fuel filter & pump
Stud—bypass filter Screw—bracket
18. Filter—oil (full flow) Flatwasher
19. Cap—oil hose Nut
20. Hose—oil drain (28 in.) 39. Tee (after 2/97)
Hose—oil drain (23 in.) 40. Valve (after 2/97)
21. Elbow—oil drain Body (after 2/97)
22. Tee Valve (after 2/97)
23. Mat—isolator (oil pressure sensor) Cap (after 2/97)
24. Elbow—flange 41. Body—fitting (after 2/97)
25. Screw—elbow
Late TK 3.95 Fuel and Oil System Components for Figure 131
