Engine Maintenance
105
1. Elbow—hose fitting (3/8) 18. Filter—oil bypass (EMI 2000)
2. Kit—sleeve & eyelet (3/8) 19. Stud—bypass filter
3. Nut (3/8) 20. Filter—oil (full flow)
4. Hose (3/8 od x 35 ft lg) 21. Tee
5. Adapter—oil line 22. Switch—oil pressure
6. Kit—sleeve & eyelet (1/4) 23. Bushing
7. Nut (1/4) 24. Fitting—restricted
8. Fitting (1/4) 25. Pump—fuel (12V)
9. Hose (1/4 od x 35 ft lg) Kit—filter
10. Tee Gasket—fuel pump
11. Tee 26. Bracket—fuel filter & pump
12. Plug Screw—bracket
13. Filter—fuel (EMI 2000) Flatwasher
14. Adapter—fuel pickup Nut
15. Bracket—fuel filter 27 Valve—Schrader
Screw 28. Elbow—oil drain
Flatwasher 29 Hose—oil drain (23 in.)
Nut 30. Cap—oil drain hose
16. Plug—pipe 31. Clip—oil drain hose
17. Plug—pipe 32. Tube—fuel pickup
TK376 Fuel and Oil System Components for Figure 132
