Engine Maintenance

117

1. Bracket - Snubber 13. Mount - Vibration

2. Plate - Front Bracket 14. Nut

Screw - Plate & Bracket (Socket Head) 15. Washer - Belleville

Washer - Belleville 16. Flatwasher

Sealer - Thread 17. Nut

3. Screw - Mount 18. Bolt - Eye

4. Flatwasher (Front Mount Only) 19. Screw - Chain

5. Mount - Vibration (Front, Set of Two) 20. Chain

6. Washer - Special 21. Stud - Snubber

7. Washer - Belleville 22. Bracket - Snubber

Nut Screw - Bracket (5/16)

9. Bracket - Engine (Rear) Flatwasher (5/16)

Screw - Bracket (Socket Head) Nut (5/16)

Sealer - Thread Screw - Bracket (3/8)

10. Mount - Vibration (Rear, Set Of Two) Flatwasher (3/8)

11. Bracket - Gauge Nut (3/8)

12. Screw - Mount

Flatwasher

TK376 Engine Mounting Components for Figure 143
