Thinget XC Series User Manual

Applied Instructions
Function & Action
Compare the assigned time with time data.
The status of the destination devices is ke
p
t
,
even if the TCMP instruction is deactivated.
：Assign the compare standard “Hour”
：Assign the compare standard “Minute”
：Assign the compare standard “Second”
S1·
S2·
S3·
z 「 ， ， 」represent hours, minutes and seconds respectively. This
time is compared to the time value in the 3 data devices specified by the head
address , The result is indicated in the 3 bit devices specified by the head
address
S1·
S2·
S3·
S·
D·
：Assign the “Hour” of clock data
＋1 ：Assign the “Minute” of clock data
＋2 ：Assign the “Second” of clock data
S·
S·
S·
， ＋ 2 ：According to the compare result, the 3 devices output ON/OFF.
The valid range of “Hour” is「0~23」.
The valid range of “Minute” is「0~59」.
The valid range of “Second” is「0~59」.
1, ＋
D·
D·
D·
Time Compare [TCMP]
16 bits instruction：DIV 32 bits instruction：DDIV
Suitable Models：
XC3、XC5
¾
Word
Device
Bit
Device
D FDDMDX DY DS TD CDK/H
S1·
S2· S3·
S·
X Y M S T C Dn.m
D·
129
