Thinget XC Series User Manual

Spec., Input/output and layout
2-5. Output Specifica
low AC250V, DC30V
tion
Interior power Be
Circuit insulation ion Mechanism insulat
Action deno mp te LED indicate la
Resistant
load
3A
Induce load 80VA
Max
load
Lamp load 100W
Open circuit’s leak
current
-
Mini load DC5V 2mA
OFF→ON 10ms Response
me
ON→OFF 10ms
ti
Interior power Below DC5~30V
Relay output
Transistor Output
Circuit insulation Optical coupling
insulation
Action denote Indicate lamp LED
Restance
load
0.8A
Induce load 12W/DC24V
Max
load
Lamp load 1.5W/DC24V
Open circuit’s leak
urrent
-
c
Mini load DC5V 2mA
OFF→ON Below 0.2ms Response
time
ON→OFF Below 0.2ms
