Special Functions
58
8-4. XC5 series PLC
8-4-1. Performance
1, Brief introduction of XC5 series
2, Performance Index
Specification
Item
32 points 48 points 60 points
Program executing format Loop scan format, time scan format
Program format Both statement and ladder
Dispose speed 0.5us
Power cut retentive Use FlashROM and Li battery
User program’s capacity 2500 steps 10000 steps
I/O points 18 I / 14 O 28/20 36/24
Interior coil’s points (M) 8512 points
Points 620 points
Timer(T)
Spec.
100mS timer: Set time 0.1~3276.7 seconds
10mS timer: Set time 0.01~327.67 seconds
1mS timer: Set time 0.001~32.767 seconds
Points 635 points
Counter(
C)
Spec.
16 bits counter: set value K0~32767
32 bits counter: set value K0~2147483647
Data Register(D) 8512 words
FlashROM Register(FD) 2048 words
High speed dispose function High speed counter, pulse output, external interrupt
Setting of time scan space 0~99mS
Password protection 6 bits ASCII
Self diagnose function Power on self-diagnose, Monitor timer, grammar check
XC5 series PLC covers all functions of XC1 series、XC3 series, also the interior source space is
larger than XC1 and XC3 series;
XC5 series PLC also have CANbus function, which can realize complex communication network
function. For the detailed CANbus function, please refer to “
TU6-8．CAN Bus (XC5 series) UT
