Thinget XC Series User Manual

Function of each device
3-6. Counter’s ID and
16 bits positive counter 299
function [C]
C0~C
32 bits positive/negative
counter
C300~C598 (C300, C302...C598) (Each one
engrosses 2 counter No.) The number must be
even.
High speed counter
C600~C634(C600,C602...C634) (Each one
engrosses 2 counter No.) The number must be
even
Counter’s ID
For the counter’s number (C), ple r to the following table: ase refe
Counter’s
characters
The characters of 16 bits counter and 32 bits counter are shown below:
Items 16 bits counter 32 bits counter
Count direction Positive Positive/negative
The set value 1~32,767 -2,147,483,648~+2,147,483,647
The assigned set
value
Constant K or data
register
Same as the left, but data register
must be in a couple
Changing of the
current value
Change after positive
count
Change after positive count (Loop
counter)
Output contact
Hold the action after
positive count
Hold the action after positive count,
reset if negative count
Reset activates
When executing RST command，counter’s current value is 0，
output contacts recover
The current value
register
16 bits 32 bits
41
