Thinget XC Series User Manual

Summary of XC series PLC
XC3 series:
Performance
Specification
Item
14 points 24/32 points 48/60 points
Program executing
format
Loop scan format, time scan format
Program format Both statement and ladder
Dispose speed 0.5us
Power cut retentive Use FlashROM and Li battery
User program’s capacity 2500 steps 8000 steps
I/O points 8 I / 6 O Input 14/18 points
Output 10/14
points
Input 28/36 points
Output 20/24 points
Interior coil’s points (M) 8512 points
Points 620 points
Timer
(T)
Spec.
100mS timer: Set time 0.1~3276.7 seconds
10mS timer: Set time 0.01~327.67 seconds
1mS timer: Set time 0.001~32.767 seconds
Points 635 points
Counter
(C)
Spec.
16 bits counter: set value K0~32767
32 bits counter: set value K0~2147483647
Data Register(D) 8512 words
FlashROM Register(FD) 2048 words
High speed dispose
function
High speed count, pulse output, external interrupt
Setting of time scan
space
0~99mS
Password protection 6 bits ASCII
Self diagnose function Power on self-diagnose, Monitor timer, grammar check
13
