Summary of XC series PLC
1-2. XC series PLC’s Model and Type
XC3
1234 5
1 Series Name XC1 series, XC3 series and XC5 series
2 I/O points
3 Input Format(NPN) R: Relay output
T: Transistor output
RT: Mix output of Transistor /Relay (Y0, Y1 are transistor)
Output Format(PNP) PR: Relay output
PT: Transistor output
PRT: Mix output of Transistor /Relay(Y0, Y1 are transistor)
4 Supply Power E: AC Power(220V)
C: DC Power(24V)
5 Clock S: With clock and RS485 COM port inside
: Without clock and RS485 COM port inside
XC1 series models:
Model
AC Power DC Power
Relay Output
Transistor
Output
Relay Output
Transistor
Output
Input
(DC24V)
Output
(R, T)
XC3-16R-E XC3-16T-E XC3-16R-C XC3-16T-C 8 points 8 points
XC3-24R-E XC3-24T-E XC3-24R-C XC3-24T-C 12 points 12 points
N
P
N
Type
XC3-32R-E XC3-32T-E XC3-32R-C XC3-32T-C 16 points 16 points
XC3-16PR-E XC3-16PT-E XC3-16PR-C XC3-16PT-C 8 points 8 points
XC3-24PR-E XC3-24PT-E XC3-24PR-C XC3-24PT-C 12 points 12 points
P
N
P
Type
XC3-32PR-E XC3-32PT-E XC3-32PR-C XC3-32PT-C 16 points 16 points
XC Series
Main Units
7
