2-1. Power Specification
For the power specification of XC series programmable controller’s basic units, please see
the following table:
AC Power
Type
Rated voltage AC100V~240V
Voltage allow bound AC90V~265V
Rated frequency 50/60Hz
Allow momentary
power-cut time
Interrupt time≤0.5 AC cycle, alternation≥1 sec
Impact current Max 40A 5mS below/AC100V
max 60A 5mS below /AC200V
Max power
consumption
12W
Power for sensor use 24VDC±10% max 400mA
• To avoid voltage decrease, please use the power cable
thicker than 2mm
2
• Even appear power cut within 10ms; PLC can still go on
working. But if long time power cut or abnormal power
decrease, PLC will stop working, output will also appear
OFF status, when recover power supply, the PLC will auto
start to work.
• Connect the grounding terminals of basic units and extend
modules together, then ground
DC power
type
Rated voltage DC24V
Voltage allow bound DC21.6V~26.4V
Input current
(Only basic unit)
120mA DC24V
Allow momentary
power-cut time
10mS DC24V
Impact current 10A DC26.4V
Max power
consumption
12W
Power for sensor
use
24VDC±10% Max 400mA
