Applied Instructions
Pulse
¾
output of single segment and single direction
2, One-direction pulse output with speedup/speed-down
• Frequency: 0~400KHz
• Speedup/speed-down time: Below 5000ms
• Output terminals: Y0 or Y1
• Output Mode: Limited pulse
• Pulse number: 16 bits instruction 0~K32767
32 bits instruction 0~K2147483647
• Instruction: PLSR
PLSR: generate certain pulse with the assigned frequency and
speedup/speed-down time.
PLSR K3000 D300 Y0
M0
K300
S1·
S2· S3·
D·
M8170
RST M0
z When M0 is ON, PLSR starts pulse output, send assigned pulse number
according to the assigned speedup/speed-down slope、highest frequency. To
output with the constant speed, set the speedup/speed-down time as 0. If set
the pulse number as H 7FFFFFFF, infinity pulse number will be sold out, at
this time coil M8170 set ON.
z When the output pulse number reaches the set value, stop pulse outputting, at
this time coil M8170 set OFF, reset M000. See the following chart
z Generate a certain quantity pulse with the assigned frequency; support 32 bits instruction [DPLSR]。
Highest frequency. Operands: K、TD、CD、D、FD
Total output pulse number. Operands: K、TD、CD、D、FD
Speedup/speed-down time. Operands: K、TD、CD D、FD
Assign Y number of output pulse, could only be output at Y000 or Y001
S1·
S2·
D·
S3·
、
216
