Applied Instructions
The bit format of the destination device is rotated n bit places to the left on every operation of the
struction
《Rotation shift left》
in
《Rotation shift right》
Function & Action
z Every time when X000 turns from OFF
to ON, executes n bits left rotation.
z Every time when X000 turns from
OFF to ON, executes n bits right
rotation.
[ROL] & [ROR]
16 bits instruction：ROL、ROR 32 bits instruction：DROL、DROR
Suitable Models：
XC3、XC5
Word
Device
Bit
Device
D
FD
DM
DX
DY
DS
TD
CD
K/H
D·
n
X
Y
M
S
T
C
Dn.m
103
