Thinget XC Series - List of Special FLASH Data Register SFD

Special Functions
53
8-2. List of special FLASH data register SFD
1、 I filter
Number Function Description
FD8000 X port, input filter time value Unit: ms
FD8002
FD8003
FD8004
FD8005
FD8006
FD8007
FD8008
FD8009
2、 I mapping
Number Function Description
FD8010 X00 corresponds with I** X0 corresponds with the number of input image I**
FD8011 X01 corresponds with I**
FD8012 X02 corresponds with I**
…… ……
FD8073 X77 corresponds with I**
3、 O mapped
Number Function Description
FD8074 Y00 corresponds with I** Y0 corresponds with the number of input image O**
FD8075 Y01 corresponds with I**
FD8076 Y02 corresponds with I**
…… ……
FD8137 Y77 corresponds with I**
4、 I property
Number Function Description
FD8138 X00 property 0: positive logic；others: negative logic
FD8139 X01 property
FD8140 X02 property
…… ……
FD8201 X77 property
5、 Device’s power failure retentive area
Number Function Description
FD8202 Start tag of D power failure store area
FD8203 Start tag of M power failure store area
FD8204 Start tag of T power failure store area
FD8205 Start tag of C power failure store area
FD8206 Start tag of S power failure store area
