Thinget XC Series User Manual

Special Functions
3
2, RS485 COM Port
3, CAN Port
Station Modbus Station number: 1~254, 255 (FF) is free format
communication
Baud Rate 300bps~115.2Kbps
Data Bit 8 bits data bit, 7 bits data bit
Stop Bit 2 stop bits, 1 stop bit
Check Even, Odd, No check
About RS485 COM port, A is “+” signal、B is “-“ signal.
On XC series PLC, COM2 (Port2) can be both RS485 and RS232, so, you can’t only use two at the
same time.
CAN port can be used to realize CANbus communication.
please refer to“6-8．CAN bus function
(XC5 series)”
For the detailed CAN communication function,
Communication Parameter
The defaulted parameters of COM 1：
Station number is 1、baud rate is 19200bps、8 data bit、1 stop bit、Even check
