Summary of XC series PLC
1-4. General Specification
Items Specifications
Insulate voltage Up to DC 500V 2MΩ
Anti-noise 1000V 1uS pulse per minute
Ambient
temperature
0°C~60°C
Ambient humidity 5%~95%
COM 1 RS-232, connect with host machine, HMI program or debug
COM 2 RS-232/RS-485, connect with network or aptitude instrument,
inverters etc.
COM 3 BD board COM port RS-232C/RS-485
COM 4 CANBUS COM port (XC5 series)
Installation Can use M3 screw to fix or install directly on DIN46277
(Width 35mm) orbit
Grounding The third type grounding (can’t public ground with strong
power system.)
General
Specification
12
