8-4-2. Soft unit’s bound:
Soft unit’s bound:
Bound Points
Mnemonic Name
32 points 48\60 points 32 points 48\60 points
X Input relay X000~X021
X000~X033
X000~X047
18 points 28\36 points
Y Output relay Y000~Y015
Y000~Y023
Y000~Y027
14 points 20\24 points
M0~M2999 【M3000~M7999】 8000
M Interior relay
M8000~M8511 for special using 512
S Flow S0~S511【S512~S1023】 1024
T0~T99：100ms not accumulation
T100~T199：100ms accumulation
T200~T299：10ms not accumulation
T300~T399：10ms accumulation
T400~T499：1ms not accumulation
T500~T599：1ms accumulation
T Timer
T600~T618：1ms with interruption precise
time
620
C0~C299：16 bits forth counter
C300~C589：32 bits forth/back counter
C Counter
C600~C634：high-speed counter
635
D0~D3999 【D4000~D7999】 8000
D Data Register
For special usage D8000~D8511 512
FD0~FD1535 4096
FD
FlashROM
Register
For special usage FD8000~FD8009 1024
