Thinget XC Series User Manual

Applied Instructions
5-4. Contactor’s Compare Instructions
monic ¾ Function
Mnemonic & Function
Mne
LD＝ Initial comparison contact. Active when the comparison (S1)＝ . (S2) is true
LD＞ Initial comparison contact. Active when the comparison (S1)> (S2) is true
LD＜ parison contact. Active when the comparison (S1)< (S2) is true Initial com
LD＜＞ Initial comparison contact. Active when the comparison (S1)≠(S2) is true
LD＜＝ Initial comparison contact the comparison (S1)≤(S2) is true . Active when
LD＞＝ Initial comparison contact. Active when the comparison (S1)≥(S2) is true
AND＝ omparison contact the comparison (S1)＝(S2)is true. Serial c . Active when
AND＞ Serial comparison contact. Active when the comparison (S1)> (S2) is true.
AND＜ Serial comparison contact. Active when the comparison (S1)< (S2) is true.
AND＜＞ Serial comparison contact. Active when the comparison (S1)≠(S2) is true.
AND＜＝ Serial comparison contact. Active when the comparison (S1)≤(S2) is true.
AND＞＝ Serial comparison contact. Active when the comparison (S1)≥(S2) is true.
OR＝ Parallel comparison contact. Active when the comparison (S1)＝(S2) is true.
OR＞ Parallel comparison contact. Active when the comparison (S1)> (S2) is true.
OR＜ Parallel comparison contact. Active when the comparison (S1)< (S2) is true.
OR＜＞ Parallel comparison contact. Active when the comparison (S1)≠(S2) is true.
OR＜＝ Parallel comparison contact. Active when the comparison (S1)≤(S2) is true.
OR＞＝ Parallel comparison contact. Active when the comparison (S1)≥(S2) is true.
148
