2-28
2
DRIVE MOTOR 2.12
Parts Illustration
Fig. C1892 shows an exploded view of the hydraulic
torque motor. Before disassembling the torque motor,
clean the outer surface of all loose dirt and grease and dry
with compressed air. Be sure all openings are plugged to
prevent solvent or soap entering the torque motor.
WARNING
To avoid eye injury, use safety goggles when clean-
ing with compressed air.
When making repairs to the hydraulic system, keep
the work area and parts clean. Use caps and plugs
on all open line and ports.
IMPORTANT
C2786
1
17
18
19
18
17
16
15
14
25
3
12
11
10
8
9
22
21
3
3
13
3
3
2
24
3
5
3
6
3
7
4
23
16
20
