64
(A37) Phantom power ON/OFF setting
(when the AN-001T is used and ANC operation is set to ACTIVE)
A N C - P H A N T O M O F F
(A36) Input Sensitivity setting
(when the AN-001T is used and ANC operation is set to ACTIVE)
A N C - S E N S I T I V I T Y - 1 0
(A38) ANC-activated output setting (when the AN-001T is used and ANC operation is set to ACTIVE)
A N C - A P P L I E S - > O U T 1
(A35) ANC operation ON/OFF setting (when the AN-001T is used)
A N C 1 - ACTIVE
(A34) Input channel name setting
A N C 1 -
- - - - - - - -
The flashing portion is the cursor position for entering channel name characters.
Select a character from the alphanumeric character list by rotating the Parameter setting knob, then move the
cursor with the Right shift key.
Entering a new name overwrites the existing name, if there is.
To delete the character, select [ _ ] (under-bar) with the Parameter setting knob. A space character cannot be
entered.
Up to 7 characters can be used to set the name.
Even when an input channel name has been set, some setting screens display the channel number, not the
set name.
When an input channel is stereo-linked (p. 76-C1), the name entry screen only for the odd channel is
displayed.
7 characters (default: IN1 – 8)
Setting Range
Set the ANC operation (p. 40, "Glossary") on or off.
• ACTIVE: Activates the ANC function.
• BYPASS: ANC function does not work.
ACTIVE, BYPASS (default)
Setting Range
Select the input sensitivity from the following 9 levels depending on the input sources:
–60, –54, –48, –42, –36, –30, –24, –18, –10 dB (default)
Setting Range
Set the Phantom power to ON or OFF.
• ON: Supplies the phantom power.
• OFF: Does not supply the phantom power.
ON, OFF (default)
Setting Range
Set on which output channel the ANC function works.
OUT1 – 2, Max. 8 when T-001Ts are used (default: OUT1)
Setting Range
